| Attenuation Low Range |
19 dBA |
| Attenuation High Range |
25 dBA |
| Back Pressure High-Range (Metric) |
76 mm HG |
| Back Pressure High Range |
2.99 in HG |
| Back Pressure Low Range |
0.98 in HG |
| Back Pressure Mid Range |
2.01 in HG |
| Back Pressure Low-Range (Metric) |
25 mm HG |
| Back Pressure Mid-Range (Metric) |
51 mm HG |
| Body Diameter |
8-45/64 in (22.11 cm) |
| Body Length |
34-1/4 in (87 cm) |
| Diameter |
8-45/64 in (22.11 cm) |
| Length |
34-1/4 in (87 cm) |
| Outlet Diameter |
3 in (7.62 cm) |
| Overall Length |
41-1/4 in (104.78 cm) |
| Rated Flow High Range |
900 cfm (25,5 m³/min) |
| Rated Flow Low Range |
537 cfm (15,2 m³/min) |
| Rated Flow Mid Range |
900 cfm (25,5 m³/min)[delete] |
| Length Range |
34 to 35 in |
| Style |
Style 1 |
