| Attenuation Low Range |
15 dBA |
| Attenuation High Range |
18 dBA |
| Back Pressure High-Range (Metric) |
76 mm HG |
| Back Pressure High Range |
2.99 in HG |
| Back Pressure Low Range |
0.98 in HG |
| Back Pressure Mid Range |
2.01 in HG |
| Back Pressure Low-Range (Metric) |
25 mm HG |
| Back Pressure Mid-Range (Metric) |
51 mm HG |
| Body Diameter |
10-63/64 in (27.9 cm) |
| Body Length |
35-3/4 in (90.81 cm) |
| Diameter |
11-5/64 in (28.14 cm) |
| Diameter Range |
5 to 6 in |
| Inlet Diameter |
4 in (10.16 cm) |
| Length |
35-1/2 in (90.17 cm) |
| Outlet Clock Position |
12:00 |
| Outlet Diameter |
5 in (12.7 cm) |
| Overall Length |
44 in (111.76 cm) |
| Rated Flow High Range |
2391 cfm (67,71 m³/min) |
| Rated Flow Low Range |
1381 cfm (40 m³/min) |
| Rated Flow Mid Range |
2391 cfm (67,71 m³/min)[delete] |
| Length Range |
35 to 36 in |
| Style |
Style 2A |
