| Attenuation Low Range |
19 dBA |
| Attenuation High Range |
25 dBA |
| Back Pressure High-Range (Metric) |
76 mm HG |
| Back Pressure High Range |
2.99 in HG |
| Back Pressure Low Range |
0.98 in HG |
| Back Pressure Mid Range |
2.01 in HG |
| Back Pressure Low-Range (Metric) |
25 mm HG |
| Back Pressure Mid-Range (Metric) |
51 mm HG |
| Body Diameter |
10-63/64 in (27.9 cm) |
| Body Length |
50-33/64 in (128.32 cm) |
| Diameter |
11-1/16 in (28.11 cm) |
| Diameter Range |
5 to 6 in |
| Inlet Diameter |
5 in (12.7 cm) |
| Length |
50-1/2 in (128.27 cm) |
| Outlet Diameter |
5 in (12.7 cm) |
| Overall Length |
57 in (144.78 cm) |
| Rated Flow High Range |
2201 cfm (62,33 m³/min) |
| Rated Flow Low Range |
1300 cfm (37 m³/min) |
| Rated Flow Mid Range |
2201 cfm (62,33 m³/min)[delete] |
| Length Range |
More than 50 in |
| Style |
Style 1 |
