SCN Adjustable Plain Trolley, 1000 lbs, fits I-Beam Flange 2-11/16 in - 5-3/8 in, Cast Iron, for Straight/Curved Tracks
#SCNLS551
Product Overview
Adjustable Trolleys with a capacity of 1000 lbs each, designed to easily adjust to fit various flanges, I-beams, and H-beams. These trolleys can be used on straight or curved tracks and can be installed or removed at any position on the beam. They feature heavy-duty cast iron wheels and a deep width flange that provides superior contact with the beam. A safety plate is included, and the product meets ASME B30.16 standards
Features & Benefits
- Easily adjusts to fit various flanges, I-beams and H-beams
- Use on straight or curved track
- Can be installed or removed at any position on the beam
- Heavy-duty cast iron wheels
- Deep width flange provides superior contact with the beam
- Safety plate included
- Meets ASME B30.16
Specifications
| A (in.) | 8.1875 |
| Application | For use on straight or curved tracks |
| Body Material | Steel |
| Capacity | 1000 lbs |
| Height | 4.921875 in |
| Includes | Safety plate |
| Length | 8.1875 in |
| Material | Cast Iron |
| Product Category | Plain Trolleys |
| Quantity | 1 |
| Size | 2-11/16 in - 5-3/8 in |
| Type | Plain |
| Voltage | 110 V |
| Width | 8 in |
| Manufacturer Part Number | LS551 |
| Fits Models | Various flanges, I-beams, H-beams |
