Signal-Stat, Incandescent, Red/Clear Polycarbonate Lens, LH, Combo Box Light, 3 Stud , Screw Terminal, 12V
#TRL4017
Product Overview
Signal-Stat, Incandescent, Red/Clear Polycarbonate Lens, LH, Combo Box Light, 3 Stud , Screw Terminal, 12V
Specifications
| Color | Red, White |
| Contents | Replaces International # 424537-C91, 424538-C91, |
| Current Major | 2.1 amp |
| Current Minor | 0.59 amp |
| Depth | 2-21/32 in (6.76 cm) |
| Function | A, I, L, R2, S, T |
| Height | 6-3/4 in (17.15 cm) |
| Includes | Gasket |
| Kit (Y/N) | No |
| # Lamp Prongs | 4 |
| Lamp Type | Bulb Replaceable |
| Length | 6-3/4 in (17.15 cm) |
| Lens Height | 6-3/4 in (17.15 cm) |
| Lens Material | Polycarbonate |
| Lens Width | 5-3/4 in (14.61 cm) |
| Plug Side One | No Plug |
| Plug Side Two | No Plug |
| Position | Left Hand Side |
| Product Type | Combination Box Lights |
| Series | Signal-Stat |
| Shape | Square |
| Standard | FMVSS 108, DOT, SAE |
| Technology | Incandescent |
| VMRS Code | 034-002-013 |
| Volt | 12 V |
| Weight | 1.29 lb (0.59 kg) |
| Width | 5-3/4 in (14.61 cm) |
Interchanges & Equivalent parts:
3099698, 442L, 2572621, 812130, 84134017, 4017, 50902, 50912, 50952, SIG4017, TL4017, TLD4017, TRL4017, 4017, TL4017, 80331R, 3099698, 4017-TL, 80331R1, 8413-4017, 9228 4017, LIT4017, SIG 4017, TL 4017, TL-4017, TL4017, TLD4017, 2572621, 4017TLT, 442L, 80331R3, SIG4017, TL4017, TRL4017, 50912, 50952, 442L, 4017, 2572621, 3099698, TL4017, TLD4017, 84134017, 812130, 4017, 50902, 80331R, TL-4017, 9228 4017, 80331R1, 4017-TL, 8413-4017, TL 4017, LIT4017, SIG 4017, TL4017, TLD4017, 3099698, 442L, 80331R3, 2572621, 4017TLT
