Spicer 1760/1810 Midship Stub Shaft Driveshaft Assembly, Steel, 2.362 in Bearing Diameter, 4.242 in Butt Diameter
#SPI6.5-53-171
Product Overview
Demand genuine Spicer parts with all components needed for reliable repair. Dana's design, engineering, testing, and manufacturing processes ensure unparalleled performance that non-genuine parts cannot deliver.Drive Shaft Midship Stub Shaft, Steel, 2.362 in Bearing Dia, 4.242 in Butt Dia, 1810, 2.875 in Shoulder Dia, 0.812 in Shoulder Length, 46 Spline Count, 4 in Spline End to Bearing Shoulder, 5.312 in Spline End to Weld, 2.625 in Spline Length, 2.350 in Spline O.D., 4.500 x 0.134 in Tube
Features & Benefits
- Genuine Spicer quality and reliability
- Engineered and tested by Dana for superior performance
- Steel construction for durability
- Fits 1760/1810 series applications
Specifications
| Bolt Hole Count | 4 |
| Circ Flange Face To End Of Hub | 2 |
| Flange Type | Circulaire |
| Flange Width Diameter (in.) (A) | 4.56 |
| Hub Diameter (in.) (E) | 2.875 |
| Key Width (in.) (K) | 0.375 |
| Material | Steel |
| Package Type | Each |
| Quantity | 1 |
| Series | 1810 |
| Shoulder Diameter | 2.875 in |
| Tube Size | 4.500 x 0.134 in |
| VMRS Code | 24002060 |
| Weight (lbs) | 10.95 |
| Bearing Diameter | 2.362 in |
| Shoulder Length | 0.812 in |
| Spline Count | 46 |
| Spline End to Bearing Shoulder | 4 in |
| Spline End to Weld | 5.312 in |
| Spline Length | 2.625 |
| Spline O.D. | 2.35 |
| Product Category | Drive Shaft Midship Stub Shaft |
| Weight | 10.98 lb |
Interchanges & Equivalent parts:
| 30014-3203 |
| 6553171-SP |
| 6553171S |
| D6553171 |
| E6553171 |
| SP 6.5 53 171 |
| SP 6553171 |
| TWD6553171 |
| 1660420C1 |
| S-F117 |
| 6553171 |
