Spicer SPL250-C/B Splined Hole End Yoke Assembly, Steel, HR Style, 3.25 in Hub Diameter
#SPI250-4-351-1X
Product Overview
Demand genuine Spicer with all the components needed for the repair. Dana design, engineering, testing and manufacturing processes all work in conjunction with one another to ensure unparalleled performance that non-genuine parts simply cannot deliver.Differential End Yoke, Splined Hole, Steel, 0.14 in C-Bore Depth, 5.312 in Center Line to End Hub, 3.250 in Hub Dia, 2.312 in Length Thru Hole, 6.417 in Outside Yoke, SPL250, 46 Spline Count, 2.362 in Yoke Bearing Dimension, HR Yoke, 2.39 in Length
Specifications
| Diamètre de chapeau de roulement | 2-23/64 po |
| Profondeur d'alésage C | 0.14 |
| Ligne centrale à la fin du moyeu | 5-5/16 po |
| Diamètre du moyeu | 3-1/4 po |
| Slinger/Plug inclus (O/N) | Yes |
| Spline à développante | Yes |
| Length | 2,39 po |
| Material | Acier |
| Quantity | 1 |
| Series | SPL250 |
| Spline Count | 46 |
| Spline Diameter | 2-25/64 po |
| Type | Trou cannelé |
| VMRS Code | 22003072 |
| Weight | 14,9 lb |
| Yoke Style | HR |
| Center Line to End Hub | 5.312 in |
| Length Thru Hole | 2.312 in |
| Outside Yoke Dimension | 6.417 in |
| Yoke Bearing Dimension | 2.362 in |
| Product Category | Joug d'extrémité de différentiel |
Interchanges & Equivalent parts:
| 2603014C91 |
| N250-4-351-1X |
| 2104-25043511X |
| 125MU53P16 |
| 181MU41P7 |
| 250-4-341-1 |
| 250-4-351-1XR |
| 25043511X |
| 25043511X-SP |
| 25167095 |
| 351839C91 |
| 3969891 |
| 8081943 |
| D25043511X |
| E25043511X |
| S-14005 |
| SP 250 4 351 1X |
| SP 25043511X |
| TWD25043511X |
| 250 4 351 1X |
| 250-4-351-1X |
