Spicer Universal Joint - 1410/SPL36 Series, OSR Style, Steel, 1.188 in Bearing Cap Diameter, Non-Greasable
#SPI5-1410X
Product Overview
You expect a lot from your vehicle, and Spicer Life Series (SPL) universal joints deliver. SPL universal joints consistently outperform competitors, so you can hit the road or trail with confidence. Experience longer life, increased bearing capacity, and lower maintenance costs with Spicer Life Series (SPL) universal joints.Universal Joint, OSR Style, Round Bearing Cap, Steel, 1.188 in Bearing Cap Dia, No Greaseable, 1410/SPL36, 4.188 in Length
Features & Benefits
Features & Benefits
SPI5-1410X - Features Documents - A
SPI5-1410X - Features Documents - B
SPI5-1410X - Features Documents - C
SPI5-1410X - Features Documents - D
SPI5-1410X - Features Documents - E
SPI5-1410X - Features Documents - F
SPI5-1410X - Features Documents - G
SPI5-1410X - Features Documents - H
SPI5-1410X - Features Documents - I
SPI5-1410X - Features Documents - J
SPI5-1410X - Features Documents - K
SPI5-1410X - Features Documents - L
SPI5-1410X - Features Documents - M
SPI5-1410X - Features Documents - N
SPI5-1410X - Features Documents - O
- Journal cross is engineered with a solid cold-formed body to ensure better wear and overall strength.
- Bearing cups are heat treated for strength; precision-ground and case-hardened for durability.
- Multi-lip seal keeps grease in and contaminants out, and gets maximum retention in a wider range of environments.
- Thrust washers eliminate metal-to-metal contact, prevent wear and lower the overall operating temperature.
Specifications
| Bearing Cap Diameter | 1.188 in |
| Bearing Cap Type | OSR: Outside Snap Ring |
| U Joint Style | OSR |
| Length | 4.188 in |
| Material | Steel |
| Seal Material | Multi-lip seal |
| Series | 1410/SPL36 |
| Snap Ring (2) | 1-53/64 in |
| Snap Ring (1) | 4-3/16 in |
| Type | OSR Style |
| VMRS Code | 024002046 |
| Weight | 1.75 lb (0.79 kg) |
| Greaseable | No |
| Product Category | Universal Joint |
| Quantity | 1 |
Interchanges & Equivalent parts:
| 5801X |
| SPI5-801X |
| SPL361X |
| SPISPL36-1X |
| CP1410X |
| 5-641X |
| 5-801X |
| 5722X |
| SPL36-1X |
| SPL36-3X |
| SPL366X |
| 5-1410X |
