Straight Coolant Hose, L: 3 ft, ID: 2-1/4 in
#GAT28230
Features & Benefits
- Extreme temperature capabilities, running from -65°F to +347°F (-55°C to +175°C) continuous to +500°F (260°C) for Aramid reinforcement
- Easily identified with an orange silicone tube, reinforced with four plies of Aramid fabric and a glossy blue silicone cover
- SAE 20R1 Class A, standard wall
- Use on hose bead fitting fastened with hose clamps
Specifications
| Construction | Premium 4-Ply Polyester-Reinforced |
| Inside Diameter | 2-1/4 in (5.72 cm) |
| Inside Diameter 1 (in) | 2-1/4 in (5.72 cm) |
| Length | 3 ft (0.91 m) |
| Material | Silicone |
| Temperature Range | -65°F @ 500°F (-54°C @ 260°C) |
| Weight | 2.5 lb (1.13 kg) |
Interchanges & Equivalent parts:
| H19630 |
| EH22736 |
