Treadle Pump - Air Actuated Hydraulic 10
#OTC4031
Sommaire du produit
Combines compact size and light weight with 2-stage high performance. It is designed for operating pressures up to 10000 PSI. Vanguard Jr. gives you just what you need.
Caractéristiques et avantages
- 2 stage flexibility with high performance and a selection of units and options that lets you tailor the pump to your needs. The 2 stage operation automatically matches pump performance to the job requirements.
- The low pressure high volume stage provides fast ram approach and return. Then at approximately 200 PSI the high-pressure low-volume stage takes over to handle high force requirements.
- These pumps are ideal for hundreds of hydraulic applications such as clamping bending straightening pressing forming testing pushing and pulling. Each one is equipped with a relief valve factory set at 10000 PSI.
- Starts easily under load and has been thoroughly field tested for high cycle reliability. Comes with a 2 position / 3 way valve and 6 feet remote motor control and is 115 V. 2 gallons of oil supplied.
Spécifications
| Contient | (1) Pump |
| Pression d'air de service recommandée | 200 PSI |
| Pédale de pompe actionnée par le pied | No |
| Pédale de pompe - Sortie maximale PSI | 10,000 PSI |
