Treadle Pump - Air Actuated Hydraulic 10
#OTC4044
Product Overview
Runs large single acting rams for fast frame straightening, wheel alignment, etc. It delivers up to 45 cu. in. / min. at a maximum operating pressure of 10,000 PSI.
Features & Benefits
- It has a 2 position / 2 way valve with advance and return positions and is for use with single acting rams.
- Equipped with a 1/2 h.p. single phase, 60 Hz, 115 volt thermal protected electric motor and is designed to start under load.
- It also features a 6? remote control cord for on/off control, and comes supplied with one gallon and two quarts of oil.
Specifications
| Contents | (1) Pump |
| Treadle Pump Foot Operated | No |
| Treadle Pump Maximum PSI Output | 10,000 PSI |
