Truck & Bus V-Belt, L: 69.2 in, W: 19/32 in
#GATTR22692
Features & Benefits
- Meets SAE J636b and SAE J637 specifications.
- Oil and heat-resistant construction throughout.
- Special tensile cords give high stretch resistance.
- Special notch design resists cracking while providing tensile member support during operation.
- Deep notch pattern also allows greater flexibility over small diameter pulleys and helps keep the belt cool.
Specifications
| Angle | 40 deg |
| Belt Top Width | 1/2 to 5/8 in (1.27 to 1.6 cm) |
| Construction | Notched |
| Length | 69.78 in |
| Material | Polyester |
| Notched | Yes |
| # of Grooves | 1 |
| Section | RA |
| Length Range | 65 to 69.99 in |
| Type | Truck & Bus V-Belt |
| Weight | 0.72 lb (0.33 kg) |
| Width | 19/32 in (1.5 cm) |
Interchanges & Equivalent parts:
| 110377-A |
| 117815 |
| 12919 |
| 1311297 |
| 22694 |
| GYB22694 |
| 1184961 |
| 1311927 |
| 15A1755 |
| 2008043201 |
| 208043201 |
| 208043205 |
| 208045049 |
| 22-692 |
| 25-22692 |
| 300143 |
| 300346 |
| 300350 |
| 303351831 |
| 420436 |
| 423851 |
| 425645 |
| 425735 |
| 425741 |
| 427749 |
| 432890 |
| 433883 |
| 490 |
| 506350 |
| 5112664 |
| 5136263 |
| 5680 |
| 612134C1 |
| 670710C1 |
| 670711C1 |
| 673948C1 |
| 673948C91 |
| 673949C1 |
| 673949C91 |
| 683846C1 |
| 683948C1 |
| 700845 |
| 71184961 |
| 7E7646 |
| 804919 |
| 88GB330P185 |
| 88GB330P189 |
| 9L6649 |
| 9L6650 |
| A-71184961 |
| A115440 |
| A117815 |
| BM8223 |
| BM8223B |
| D108359 |
| GT490 |
| MF8680 |
| MF8685 |
| MS51067C6914 |
| RECMF8680 |
| RECMF8685 |
| REMF8680 |
| REMF8685 |
| T22692 |
| V396 |
| ZJG22694 |
| BM8223A |
| 109629 |
| 110377A |
| 22690 |
| 22685 |
| 22692 |
| A71184961 |
| 22694MK |
| 2522692 |
| TR22692 |
| 1370 |
| D11025052 |
| E4HS8620DA |
| E4HS8A615A |
| 612134C11 |
| 359013C91 |
| E4HS8A615F |
| V1092894 |
| 178763C1 |
| E4HS8A615FA |
| 6F-2590 |
| 3040456 |
| 17714 |
| 482159C91 |
| 482157C1 |
| 193825R1 |
| 6N-9158 |
| 6N-7721 |
| 7E-7645 |
| 4B-5418 |
| D11025051 |
| 482158C91 |
