Truck-Lite 33 Series LED License Light Kit, Clear, Round, Hardwired, 12V, 1 Diode, Grommet Mount

#TRL33010C

Product Overview

33 Series LED license light kit featuring a single diode, round shape, clear polycarbonate lens, and grommet mount design. Hardwired with .180 bullet connector, operates at 12V. Designed for easy retrofit with a 1-3/16 in mounting hole. Includes lamp and grommet. Durable, low-profile design resists damage and corrosion, with sealed epoxy electronics for moisture protection.License Light Kit, 1 Diode, LED Bulb, Hardwired, Grommet, Polycarbonate, Clear, 12.07 in H, 0.72 in L, Light Function: L, 33 Series, Round, 12 V, Warranty: 5 Years, 0.72 in W

Features & Benefits

Hardwired lamp design is easily retrofitted, with only a 1-3/16'' mounting hole required for grommet installation

US Patent 5,943,798

Product designed to fit in 33705 grommet

Top and side plate mounting options

When mounted into a module, all wires are hidden inside module, protecting against damage from corrosion

Does not require a bracket, so it can be mounted directly into the vehicle

Stealth, low-profile design is resistant to damage and hides lamp away from view to help prevent theft

LEDs draw less current, allowing more power for other vehicle requirements

Reduces lighting costs due to physical damage and heat entrapment

Electronics are completely sealed in epoxy to resist corrosion and moisture

Specifications

Bulb Type	LED
Color	White
Common Size	3/4 in
Connection Type	Hardwired
Contents	Lamp & Grommet
Depth	12-1/16 in
Diameter	23/32 in
Diamond Shell (Y/N)	No
Height	23/32 in
Housing Color	Black
Kit (Y/N)	Yes
Length	23/32 in
Lens Color	Clear
Lens Material	Polycarbonate
License Plate Light Size	1-3/16 in
Material	Polycarbonate
Mounting Type	Grommet
Mount/Trim Material	Rubber
Mount Type	Grommet Mount
Number Of Wires	2
Plug Side One	PL-2 (Stripped End)
Plug Side Two	.180 Bullet, Standard
Product Type	License Light
Quantity	5
Series	33 Series
Shape	Round
Size	1-3/16 in
Standard	FMVSS 108, CMVSS 108, DOT, SAE
Standards	FMVSS 108, CMVSS 108, DOT, SAE
Technology	LED
Type	1 Diode
UPC	735111000000
Volt	12V
Voltage Rating	12 V
Warranty	5 Years
Weight	0.08 lb
Width	23/32 in
Wire Gauge	18 ga
Current Rating	0.15 amp
Light Function	L
Light Output Color	White
Product Line	33 Series
Product Category	License Light Kit

Interchanges & Equivalent parts:

33010C

33010CTLT

TKL33010C

60721

16516685C2030

46002427
