Truck-Lite 37 Series Direct LED Headlamp 4x6 High Beam with Clear Polycarbonate Lens
Product Overview
Introducing the latest evolution in LED lighting. Truck-Lite's 37 Series Direct LED Headlights offer a modern and sleek look and are designed with projector-like optics technology that significantly improves lighting performance including a more uniform beam pattern with increased foreground lighting, strategically aimed light output at a longer and wider distance. Also available with embedded heating technology that prevents snow and ice buildup in even the worst winter conditions. Available in 7" Round, 5"x7", and 4"x6" High & Low Beam. This 4x6 high beam model features a clear polycarbonate lens and rugged die-cast aluminum housing, delivering powerful illumination with low power consumption ranging from 0.89A to 1.72A at 12.8V, ensuring brighter and more efficient lighting.Direct Headlight, 4 Diode, High Beam, Hardwired Connector, LED, Die-Cast Aluminum, Polycarbonate Lens, Clear, 0.89 to 1.72 A at 12.8 V, 0.59 to 1.23 A at 25.8 V, 3 in H, 4.2 in L, Rectangular, Standards: FMVSS 108, CMVSS 108, DOT, SAE, 6.6 in W
Features & Benefits
- Next Generation Optics Technology provides Best-in-Class beam pattern and increases light output where you need it
- Rugged construction with military grade e-coat aluminum housing and polycarbonate lens for front-end protection
- Designed with solid-state internal components impervious to shock and vibration
- DOT Compliant
- Options with Heated Technology, heat consistently under 10 degrees C / 50 degrees F.
- Clear polycarbonate lens and robust die-cast aluminum housing for durable, powerful high beam illumination
- Low power consumption range of 0.89A-1.72A at 12.8V for efficient lighting
Specifications
| Height | 3 in |
| Length | 4.2 in |
| Lens Material | Polycarbonate |
| Shape | Rectangular |
| Type | 4 Diode, High Beam |
| Weight | 1.25 lb |
| Width | 6.6 in |
| Connector Type | Hardwired |
| Current Rating | 0.89 to 1.72 A at 12.8 V, 0.59 to 1.23 A at 25.8 V |
| Finish | Military grade e-coat |
| Housing Material | Die-Cast Aluminum |
| Lamp Type | LED |
| Lens Color | Clear |
| Mounting Type | Direct |
| Operating Temperature | Under 10 degrees C / 50 degrees F |
| Standards | FMVSS 108, CMVSS 108, DOT, SAE |
| Voltage Rating | 12.8 V |
| Wattage | Approx. 11.4 to 22 W |
| Product Category | Direct Headlight |
Interchanges & Equivalent parts:
| 37645C3 |
