WELD YOKE
#ROC25RY683
Features & Benefits
- Enhance steering control with the yoke, tube, and sleeve assembly's design
- Optimize performance with the yoke, tube, and sleeve assembly's precise engineering
- Extend the lifespan of steering components with the yoke, tube, and sleeve assembly
- Ensure precise fit with yoke, tube, and sleeve assembly, maintaining vehicle stability
- Resist wear and tear due to the robust construction of yoke, tube, and sleeve assembly
- Increase durability with high-quality materials used in yoke, tube, and sleeve assembly
- Maintain alignment accuracy with the yoke, tube, and sleeve assembly's reliable components
- Improve overall vehicle handling through the yoke, tube, and sleeve assembly's functionality
Specifications
| Bearing Cap Diameter | 2-1/16 in (5.23 cm) |
| Center Line to End of Hub | 5 in (12.7 cm) |
| Centerline to Point of Weld | 3-45/64 in (9.41 cm) |
| Insert Diameter (in.) | 4-15/64 in (10.74 cm) |
| Joint Angle | 27 deg |
| Series | RPL25 |
| Use W/ Tubing OD And Wall | 4-19/32 in (11,67 cm) x 3/16 in (0,48 cm), (7 GA) |
| VMRS Code | 024-002-057 |
| Yoke Dim Across Ears | 8-21/64 in (21,16 cm) |
Interchanges & Equivalent parts:
| 25RY68-3 |
| 25RY681 |
| 25RY683-RI |
| 8235-25RY683 |
| 85107586 |
| ATI25RY683 |
| S-17261 |
| TDA 25RY68 3 |
| TDA25RY683 |
| TWD25RY683 |
| 25RY683 |
