| Air Inlet |
Air Inlet 3/4 NPTF |
| Air Spring Type |
Single Convoluted |
| Bead Plate (Top) & Deflated Bellows O.D. |
2.6 in @ 7.2 in (6.6 cm @ 18.29 cm) |
| Bellows |
Goodwill 578913301 |
| Bottom Bead Plate Hardware Key |
2 x Threaded Hole 3/8 in-16 Blind Nut on Bead Plates 1/2 in-13 Pistons |
| Bottom Plate Diameter |
9 in (22.86 cm) |
| Bottom Plate Alignment |
Parallel |
| Bottom Plate Hole/Stud Qty |
2 |
| Bumper |
Yes |
| Compressed Length |
2-45/64 in (6.86 cm) |
| Extended Length |
7-13/64 in (18.29 cm) |
| Firestone Bellows Number |
19-.75 |
| Piston (Bottom) Mounting Bolt Dimensions Center to Center |
6-13/64 in (15.75 cm) |
| Top Bead Plate Hardware Key |
2 x Threaded Hole 3/8-16 in Blind Nut on Bead Plates 1/2-13 in Pistons |
| Top Plate Diameter |
9 in (22.86 cm) |
| Top Plate Hole/Stud Qty |
2 |
| Type |
Bellows Air Springs |
| Weight |
11.8 lb (5.35 kg) |
