Air Spring - 1 Rolling Lobe - Reversible Sleeve
#ARB1R12-615
Features & Benefits
- Superior Rubber Chemistry
- Reduced Weight
- Internal Wall Cord
- Comfort
- Equipment Longevity
Specifications
| Air Inlet | Air Fitting 1/4 in NPTF, Stud 3/4-10 |
| Air Spring Type | 1 Solid Sleeve |
| Bead Plate (Top) & Deflated Bellows O.D. | 6.7 in @ 22 in (17.02 cm @ 55.88 cm) |
| Bellows | 566243164 |
| Bottom Bead Plate Hardware Key | Bold or Stud 1/2 in-13 |
| Bottom Plate Diameter | 10 in (25.4 cm) |
| Bottom Plate Alignment | Parallel |
| Bottom Plate Hole/Stud Qty | 1 |
| Bracket | Yes |
| Bumper | No |
| Compressed Length | 6-45/64 in (17.02 cm) |
| Contitech Bellow # | 910-16P |
| Extended Length | 22 in (55.88 cm) |
| Firestone Bellows Number | 1T15XMR-7 |
| Piston Height | 4-21/32 in (11.84 cm) |
| Piston Number | 566-20-7-303 |
| Piston Type | Composite |
| Plate Type | Composite |
| Top Bead Plate Hardware Key | Bold or Stud 1/2-13 in |
| Top Plate Diameter | 9 in (22.86 cm) |
| Top Plate Hole/Stud Qty | 2 |
| Type | Air Springs |
| Weight | 12.2 lb (5.53 kg) |
Interchanges & Equivalent parts:
| 1R12-615 |
| 8829 |
| AB8829 |
| W013588829 |
| W01-358-8829 |
| W01-358-8842 |
| ZAGA8829 |
| 1R12615 |
| 20505399 |
| CON79120 |
