Brake Rotor, U-Shaped
#ROC3218K167
Specifications
| Application | Meritor ADB1560 |
| Bolt Circle Diameter | 11-1/4 in |
| Brake Surface Width | 1-3/4 in |
| Diameter | 15-1/4 in |
| Diameter Range | 15 to 15.99 in |
| Discard Thickness (in.) | 1-5/8 in |
| Flange Thickness | 9/16 in (1,44 cm) |
| Height | 8-1/2 in |
| Hole Size | 13/16 in |
| Length | 16-1/2 in |
| Material | Iron |
| Model | ADB1560 |
| New Disc Thickness | 1-3/4 in |
| Number of Bolt Holes | 10 |
| Overall Depth | 6-3/32 in |
| Pilot Diameter | 8-3/4 in |
| Rotor Depth | 6-1/8 in |
| Type | U-Shaped |
| UPC | 737238089155 |
| VMRS Code | 013-017-001 |
| Weight | 67.1 lb |
| Wheel Type | Disc |
Interchanges & Equivalent parts:
| 3218K167 |
| GUNR6198 |
| R6198 |
| 90102-5009 |
| 3218K167-RI |
| 8235-3218K167 |
| ATI3218K167 |
| R6086 |
| TDA 3218K167 |
| TDA3218K167 |
| TWD3218K167 |
