| Application |
Freightliner |
| Back Pulley Diameter (A) |
5-19/32 in (14.22 cm) |
| Belt Groove Location (C) |
55/64 in (2.18 cm) |
| Center Of JB To Top Right Mounting Hole (J) |
3-29/32 in (9.93 cm) |
| Clutch Type |
DM Advantage On/Off |
| Drive Ratio |
1.29:1 |
| Engine MFR |
Caterpillar |
| Engine Model(S) |
3126 |
| Fan Blade Stud Length (F) |
0.81 |
| Horizontal Mounting Distance (H) |
3-15/64 in (8.2 cm) |
| Kit Includes |
Journal Bracket, Sheave Bearing, Sheave, Bearing Nut, Air Chamber Cap, O-Ring Seal, Fan Mounting Disc/Studs, Button Head Screws, Air Chamber Seal, Face Seal, Retaining Ring, Air Cartridge Assembly, Friction Liner, Bearing Spacers, Clutch Pack - Spring Housing/Piston |
| Length |
6-45/64 in (17.02 cm) |
| OEM # |
3244973-55/64 ft (989068 m) |
| Pilot Diameter |
2-9/16 in (6.5 cm) |
| Vehicle Model(s) |
FTZ FLD120, FLB, FLD 112, FLD 120, FLX 120, FL 106, K-100E, K-136E, T600, T800H, W900B2, T800W, T2000, Gladiator, Classic, Evolution, ALL VEHICLE MODELS |
| Vehicle Years |
1994-2005 |
| Vertical Mounting Distance (G) |
7-15/64 in (18.36 cm) |
