Goodyear
GOODYEAR AIR SPRING
#ARB1R12-424
Features & Benefits
- Superior Rubber Chemistry
- Reduced Weight
- Internal Wall Cord
- Comfort
- Firestone W01-358-9287, ContiTech 9 10-18.5 P 406, GMC 15963160, International 50405, International 50405-1, International 50405-2
Specifications
| Air Spring Type | Rolling Lobe |
| Bead Plate (Top) Mounting Bolts Dimension Center to Center | 6-13/64 in (15.75 cm) |
| Bellows | Automann 1DK23M, Firestone 1T15M-8, Goodwill 566241012, Contitech 9 10-18.5, Triangle 6363/91 |
| Bottom Plate Alignment | 90 deg |
| Bottom Plate Diameter | 10-1/8 in (25.73 cm) |
| Bottom Plate Hole Stud Qty | 2 |
| Bracket | Yes |
| Bumper | No |
| Compressed Length | 8-3/32 in (20.55 cm) |
| Contitech Bellow # | 9 10-18.5 |
| Firestone Bellows Number | 1T15M-8 |
| Goodyear Bellow # | 566241012 |
| Height | 21 in (53.34 cm) |
| Length | 12 in (30.48 cm) |
| Maximum Height | 20 in (50.8 cm) |
| Plate Type | Steel |
| Quantity | 1 |
| Top Plate Diameter | 9 in (22.86 cm) |
| Top Plate Hole Count | 2 |
| Triangle Bellows Number | 6363/91 |
| Type | Rolling Lobe Air Springs |
| Weight | 24 lb (10.88 kg) |
| Width | 12 in (30.48 cm) |
