Goodyear
GOODYEAR AIR SPRING
#ARB1R12-508
Features & Benefits
- Superior Rubber Chemistry
- Reduced Weight
- Internal Wall Cord
- Comfort
- Firestone W01-358-8204, Firestone 9307, Firestone 9334, ContiTech 9 10-12 P 484, ContiTech 9 10-10 P 471, ContiTech 9 10-10 P 482, Neway 905-57-173, Neway 905-57-223
Specifications
| Air Spring Type | Rolling Lobe |
| Bead Plate (Top) Mounting Bolts Dimension Center to Center | 5-1/2 in (13.97 cm) |
| Bellows | Automann 1DK23H, Firestone 1T15M-2, Goodwill 566243002, Contitech 9 10-12, Triangle 6361, 6388 |
| Bottom Plate Alignment | Parallel |
| Bottom Plate Diameter | 9-19/64 in (23.62 cm) |
| Bottom Plate Hole Stud Qty | 1 |
| Bumper | Yes |
| Compressed Length | 4-1/2 in (11.43 cm) |
| Contitech Bellow # | 9 10-12 |
| Firestone Bellows Number | 1T15M-2 |
| Goodyear Bellow # | 566243002 |
| Height | 11 in (27.94 cm) |
| Length | 12 in (30.48 cm) |
| Maximum Height | 14-3/32 in (35.79 cm) |
| Plate Type | Composite |
| Quantity | 1 |
| Top Plate Diameter | 9 in (22.86 cm) |
| Top Plate Hole Count | 2 |
| Triangle Bellows Number | 6361, 6388 |
| Type | Rolling Lobe Air Springs |
| Weight | 13.5 lb (6.12 kg) |
| Width | 10 in (25.4 cm) |
