Goodyear
GOODYEAR AIR SPRING
#ARB1R13-120
Features & Benefits
- Superior Rubber Chemistry
- Reduced Weight
- Internal Wall Cord
- Comfort
- Firestone W01-358-9218, ContiTech 11 10.5-15 A 422, Neway 905-57-209, Ridewell 1003589218C, Watson & Chalin AS-0073
Specifications
| Air Spring Type | Rolling Lobe |
| Bead Plate (Top) Mounting Bolts Dimension Center to Center | 5-1/2 in (13.97 cm) |
| Bellows | Automann 1DK28L, Firestone 1T19F-5, 1T19L-5, Goodwill 566263038, Contitech 11 10.5-15, Triangle 6417 |
| Bottom Plate Alignment | 45 deg |
| Bottom Plate Diameter | 11-45/64 in (29.72 cm) |
| Bottom Plate Hole Stud Qty | 4 |
| Bumper | Yes |
| Compressed Length | 5-45/64 in (14.48 cm) |
| Contitech Bellow # | 11 10.5-15 |
| Firestone Bellows Number | 1T19F-5, 1T19L-5 |
| Goodyear Bellow # | 566263038 |
| Height | 14 in (35.56 cm) |
| Length | 12 in (30.48 cm) |
| Maximum Height | 18 in (45.72 cm) |
| Plate Type | Aluminum |
| Quantity | 1 |
| Top Plate Diameter | 11-19/64 in (28.7 cm) |
| Top Plate Hole Count | 2 |
| Triangle Bellows Number | 6417 |
| Type | Rolling Lobe Air Springs |
| Weight | 24.5 lb (11.11 kg) |
| Width | 12 in (30.48 cm) |
