Goodyear
GOODYEAR AIR SPRING
#ARB2B9-239
Features & Benefits
- Superior Rubber Chemistry
- Reduced Weight
- Internal Wall Cord
- Comfort
- Firestone W01-358-6902, ContiTech FD 200-19 310, Ridewell 1003586902C, Watson & Chalin AS-0002
Specifications
| Air Spring Type | Double Convoluted |
| Bead Plate (Top) Mounting Bolts Dimension Center to Center | 3-1/2 in (8.89 cm) |
| Bellows | Automann SP2B12R, Firestone 20F was 20, Goodwill 578923211, Contitech FD 200-19, Triangle 6325 |
| Bottom Plate Alignment | Parallel |
| Bottom Plate Diameter | 6-13/32 in (16.28 cm) |
| Bottom Plate Hole Stud Qty | 2 |
| Bumper | Yes |
| Compressed Length | 3-29/32 in (9.93 cm) |
| Contitech Bellow # | FD 200-19 |
| Firestone Bellows Number | 20F was 20 |
| Goodyear Bellow # | 578923211 |
| Height | 9 in (22.86 cm) |
| Length | 12 in (30.48 cm) |
| Maximum Height | 10-19/64 in (26.16 cm) |
| Quantity | 1 |
| Top Plate Diameter | 6-13/32 in (16.28 cm) |
| Top Plate Hole Count | 3 |
| Triangle Bellows Number | 6325 |
| Type | Bellows Air Spring |
| Weight | 9 lb (4.08 kg) |
| Width | 12 in (30.48 cm) |
