Goodyear Rolling Lobe Air Spring with Composite Piston, 7-1/2 in Compressed Length, 21-1/8 in Extended Length
Product Overview
Super-Cushion air springs for trucks, trailers, buses, and cab and seat springs protect cargo, provide constant-level hauling, and deliver long, trouble-free service. These air springs offer a quiet, cushioned ride, reducing vibration to extend the life of truck, trailer, and bus bodies. Drivers benefit from greater comfort and reduced fatigue, while cargo is better protected from shock and vibration. Super-Cushion air springs fit easily when adding an axle and, when used with leveling valves, maintain consistent trim regardless of load, keeping clearance heights constant and trailer floors flush with loading docks for easy loading and unloading. Specify Goodyear engineered Super-Cushion air springs for driver comfort, load cushioning, and long service life.Air Spring, Rolling Lobe Air Spring, Composite Piston, 7-1/2 in Compressed Length, 21.1 in Extended Length
Features & Benefits
- Superior Rubber Chemistry
- Reduced Weight
- Internal Wall Cord
- Comfort
- Firestone W01-358-9069, ContiTech 9 10-14 P 312, Flexmember 566-24-3-163, Piston 566-20-7-235, Dayton 352-9069, Fleetride 1R12-1052, International 554761C1, Watson & Chalin AS-0077, Peterbilt 03-01649, Peterbilt 03-02038, Peterbilt 03-02456, Peterbilt 03-04759, Peterbilt 03-07112, Peterbilt 23-10042
Specifications
| Air Spring Type | Rolling Lobe |
| Application | Trucks, trailers, buses, cab and seat springs |
| Bellows | Automann 1DK23I, Firestone 1T15M-4/1T15VP-4, Goodwill 566243038, Contitech 9 10-13.5/9 10-14, Triangle 6362/85/88 |
| Bottom Plate Diameter | 9-51/64 in |
| Bottom Plate Alignment | Parallel |
| Bottom Plate Hole/Stud Qty | 1 |
| Bumper | Yes |
| Compressed Length | 7-1/2 in |
| Contitech Bellow # | 9 10-13.5/9 10-14 |
| Extended Length | 21-3/32 in |
| Firestone Bellows Number | 1T15M-4/1T15VP-4 |
| Height | 14 in |
| Length | 10 in |
| Plate Type | Aluminum |
| Ride Height | Maintains consistent trim regardless of load |
| Top Plate Diameter | 9 in |
| Top Plate Hole/Stud Qty | 2 |
| Triangle Bellows Number | 6362/85/88 |
| Type | Rolling Lobe Air Springs |
| Weight | 16 lb (7.26 kg) |
| Width | 10 in |
| Capacity | Load cushioning and constant-level hauling |
| Finish | Aluminum |
| Fits Models | Firestone W01-358-9069, ContiTech 9 10-14 P 312, Flexmember 566-24-3-163, Piston 566-20-7-235, Dayton 352-9069, Fleetride 1R12-1052, International 554761C1, Watson & Chalin AS-0077, Peterbilt 03-01649, Peterbilt 03-02038, Peterbilt 03-02456, Peterbilt 03-04759, Peterbilt 03-07112, Peterbilt 23-10042 |
| Includes | Bumper |
| Product Category | Air Spring |
Interchanges & Equivalent parts:
| 9069 |
| AB9069 |
| W01-358-9069 |
| 1R12-069 |
| W013589069 |
| ZAGA9069 |
| 1R12-669 |
| 1300248000 |
| 1R12069 |
| AS90690 |
| C816022 |
| CON73569 |
