Grote LED Amber Directional Warning Light, Ultra-Low Profile, Clear Lens, Rectangular, Die-Cast Aluminum, S-Link™ Compatible
Product Overview
Ultra-low profile LED directional warning lights offer a reliable, high-intensity solution with wide-angle visibility and robust die-cast aluminum construction. Features include single and split color options, 25 built-in flash patterns, and S-Link™ System compatibility for synchronization with up to eight interconnected modules. Designed for versatile mounting with grommet or optional surface bezels, this LED directional warning lamp meets SAE J595 standards and operates reliably in temperatures from -40 to 55°C.Directional Warning Lamp, Low Profile, Blunt Cut Connection Type, LED, Surface Mounting, Clear Lens, Polycarbonate/Aluminum, 0.55 A Current Rating, 22 GA Gauge, -40 to 55 deg C Operating Temperature, Class I SAE, Rectangular, SAE J595 Standards, 12/24 V, 5 Years Warranty, 0.39 in Height, 4.95 in Length, 1 in Width
Features & Benefits
- Only .84" thin profile for discreet installation
- Selectable flash patterns in 2 phases + steady-on
- Synchronize with up to eight other S-Link™ system units
- Compatible with other S-Link™ products for versatile use
- Grommet mount convertible to surface mount with optional bezels
- Robust die-cast aluminum base with polycarbonate lens
- Self-contained high intensity, wide angle LED module
- 25 built-in flash patterns for versatile signaling
- Meets SAE J595 Class I standards
Specifications
| Common Size | 4 po |
| Connection Type | Coupe franche |
| Gauge | 22 GA |
| Height | 0,39 po |
| Length | 4,95 po |
| Lens Color | Transparent |
| Material | Aluminium / Polycarbonate |
| Mounting Type | Montage sur oeillet convertible en montage en surface |
| Operating Temperature | -40 à 55°C |
| SAE Class | Classe I |
| Shape | Rectangulaire |
| Standards | SAE J595 |
| Type | Low Profile |
| VMRS Code | 034-001-021 |
| Voltage Rating | 12/24 V |
| Warranty | 5 Years |
| Width | 1 in |
| Current Rating | 0.55 A |
| Light Pattern | 25 built-in flash patterns |
| Light Type | LED |
| Product Category | Directional Warning Lamp |
Interchanges & Equivalent parts:
| 92696Y |
| 7376-78143 |
| 78143GR0 |
| GRO78143 |
| 78143 |
| 8-30057 |
| 8-33087 |
| 8-49077 |
| 8-49157 |
| 2-401 |
| 4095 |
| 41 |
| 50-3050A-3 |
| M84420-B |
| 7302741 |
| 730-2741 |
| 7308297 |
| 730-8297 |
