HD Plus All Steel Brake Chamber, T30, S-Cam, 3 in Stroke, 9.75 in Push Rod, 5/8-11 UNC Mount
#TSEHD30S-LS
Product Overview
Superior OEM preferred design with rigorous durability testing simulating real-world conditions for unmatched reliability. Features proprietary TSE Sealed When It Counts™ technology for moisture and contaminant protection, patented low temperature synthetic grease bushing to reduce leaks and brake drag, and a dust cap with pressure relief to prevent back pressure or vacuum in the spring compartment. Designed with a high vibration mounting base for longer life and optional fixed-position clevis with stainless steel pins for maximum corrosion protection.Brake Chamber, S-Cam Brake, 30-30 Chamber, Steel, 3/8-18 NPTF Inlet Port, 5/8-11 UNC Mounting Stud, 7.35 in Push Rod Length, 3 in Stroke Length, 8.2 in Width, For Trailer
Features & Benefits
- HD Plus by TSE
- Proprietary TSE Sealed When It Counts™ technology protects against moisture and contaminants
- 4 year warranty standard. 5 years for fleet partners
- Sets industry standard for long life & corrosion protection
- Sets industry standard for long life & corrosion protection
- Rigorous testing simulates real-world operating conditions for unmatched reliability
- Patented bushing prepacked with low temperature synthetic grease reduces center section leaks and brake drag
- All Steel Design
- Dust cap with pressure relief feature prevents back pressure or vacuum in spring compartment
Specifications
| Clevis | Yes |
| Contains | Brake Chamber |
| Material | Steel |
| Model | T30 |
| Product Type | S-Cam Drum Brakes |
| Push Rod Length (in.) | 9-3/4 in (24.77 cm) |
| Stroke | 3 in |
| Stroke Inch | 3 in (7.62 cm) |
| Type | Service Chamber |
| Application | Trailer |
| Brake Type | S-Cam |
| Includes | Clevis |
| Port Size | 3/8-18 NPTF |
| Stroke Type | Round Ports |
| Product Category | Brake Chamber |
Interchanges & Equivalent parts:
| 3000SCLS |
| 30SCN3 |
| EBC30SEL |
| HD30SLS |
| HD30S-LS |
| 30SCN3-3413 |
