Marker Clearance Light, Red, Rectangular
#TRL12275R
Product Overview
12 Series, LED, Red Rectangular, 6 Diode, Marker Clearance Light, PC, PL-10, 12V
Features & Benefits
- SAE PC-rated for combination clearance/marker applications
- Lamp gasket #97921 required for proper lamp and bracket fit
Specifications
| Color | Red |
| Common Size | 2 in (5.08 cm) |
| Contents | Marker Clearance Light |
| Current Major | 0.12 amp |
| Depth | 2-1/32 in (5.16 cm) |
| Diamond Shell (Y/N) | No |
| Height | 1-59/64 in (4.88 cm) |
| Kit (Y/N) | No |
| Length | 2-29/32 in (7.39 cm) |
| Lens Material | Polycarbonate |
| Material | Polycarbonate |
| Mount Type | Bracket Mount |
| Number Of Wires | 2 |
| Reflectorized (Y/N) | No |
| Series | 12 Series |
| Shape | Rectangular |
| Standard | FMVSS 108, CMVSS 108, DOT, SAE |
| Technology | LED |
| Type | Marker Clearance Light |
| VMRS Code | 034-004-253 |
| Volt | 12V |
| Width | 4-29/32 in (12.47 cm) |
Interchanges & Equivalent parts:
| 12275R |
| MCL86RB |
| TL12275R |
| TLD12275R |
| 841312275R |
| 8413-12275R |
| TL 12275R |
| LIT12275R |
| MCL-86RB |
| TL 12275R |
