Marker Clearance Light, Red, Rectangular
#TRL35201R
Product Overview
35 Series, LED, Clear/Red Rectangular, 2 Diode, Marker Clearance Light, P2, 2 Screw, Fit 'N Forget M/C, 12V
Features & Benefits
- Clear Lens Colored LEDs
- Unique Combination Of Colored LEDs w/ Clear Lens Draws Attention To Lamp Only When Lit
- Slim 3/4 Inch Wide Design Makes Lamp Perfect Solution For Narrow Rails
- Must Be Mounted Horizontally
- Optional Sealing Gasket #97035 Available To Improve Seal Between Lamp & Body Of Vehicle
- Requires A Fit 'n Forget Connector, Recommend Part Number 94862
- Not Suitable For PC Requirements
Specifications
| Color | Red & White |
| Common Size | 1 in (2.54 cm) |
| Contents | Marker Clearance Light |
| Current Major | 0.05 amp |
| Depth | 1-1/4 in (3.18 cm) |
| Diamond Shell (Y/N) | No |
| Height | 3/4 in (1.91 cm) |
| Housing Color | Clear |
| Kit (Y/N) | No |
| Length | 4 in (10.16 cm) |
| Lens Material | Polycarbonate |
| Material | Polycarbonate |
| Mount Type | Side Mount |
| Number Of Wires | 2 |
| Reflectorized (Y/N) | No |
| Series | 35 Series |
| Shape | Rectangular |
| Standard | FMVSS 108, CMVSS 108, DOT, SAE |
| Technology | LED |
| Type | Marker Clearance Light |
| VMRS Code | 034-004-253 |
| Volt | 12V |
| Width | 4 in (10.16 cm) |
Interchanges & Equivalent parts:
| 35201R |
| 8413-35201R |
| 9522RC-88 |
| TL 35201R |
| TL 35201R |
| TL35201R |
| TLD35201R |
