Signal-Stat, Arrow Lens, Incandescent, Red Square, 2 Bulb, Rear Turn Signal, 4 Screw, Hardwired, Stripped End, 12V
#TRL6501
Product Overview
Signal-Stat, Arrow Lens, Incandescent, Red Square, 2 Bulb, Rear Turn Signal, 4 Screw, Hardwired, Stripped End, 12V
Specifications
| Color | Red |
| Current Major | 2.1 amp |
| Current Minor | 0.5 amp |
| Depth | 1-7/8 in (4.78 cm) |
| Height | 7-3/8 in (18.75 cm) |
| Kit (Y/N) | No |
| Lamp Type | Bulb Replaceable |
| Length | 6-3/4 in (17.15 cm) |
| Lens Height | 7-3/8 in (18.75 cm) |
| Lens Material | Acrylic |
| Lens Width | 7-3/8 in (18.75 cm) |
| Number Of Wires | 1 |
| Plug Side One | PL-2 (Stripped End) |
| Plug Side Two | PL-2 (Stripped End) |
| Position | Rear |
| Product Type | Turn Signal |
| Series | Signal-Stat |
| Shape | Square |
| Standard | FMVSS 108, CMVSS 108, DOT, SAE |
| Technology | Incandescent |
| VMRS Code | 034-002-013 |
| Volt | 12V |
| Weight | 1.03 lb (0.47 kg) |
| Width | 7-3/8 in (18.75 cm) |
| Wire Gauge | 16 ga |
Interchanges & Equivalent parts:
| 6501 |
| SIG6501 |
| TLD6501 |
| 6501S1G |
| 8413-6501 |
| LIT6501 |
| TL 6501 |
| TL6501 |
