Signal-Stat, Incandescent, Red/Clear Acrylic Lens, RH, Combo Box Light, 2 Stud , Packard , 12V
#TRL5016
Product Overview
Signal-Stat, Incandescent, Red/Clear Acrylic Lens, RH, Combo Box Light, 2 Stud , Packard , 12V
Features & Benefits
- Mack #14M052M, 14MO52AM
- Used on tractors, trucks and 4 wheel drive vehicles
- Conforms to current DOT and SAE Standards
Specifications
| Application | Mack |
| Color | Red & White |
| Current Major | 2.1 amp |
| Current Minor | 0.59 amp |
| Depth | 2-3/64 in (5.21 cm) |
| Fits Pigtail Part #(s) | 9470 |
| Height | 6-3/4 in (17.15 cm) |
| Kit (Y/N) | No |
| # Lamp Prongs | 5 |
| Lamp Type | Bulb Replaceable |
| Length | 6-3/4 in (17.15 cm) |
| Lens Height | 6-3/4 in (17.15 cm) |
| Lens Material | Acrylic |
| Lens Width | 5-3/4 in (14.61 cm) |
| Plug Side Two | No Plug |
| Position | Right Hand Side |
| Product Type | Combination Box Lights |
| Series | Signal-Stat |
| Shape | Square |
| Standard | FMVSS 108, DOT, SAE |
| Technology | Incandescent |
| VMRS Code | 034-002-013 |
| Volt | 12V |
| Weight | 1.45 lb (0.66 kg) |
| Width | 5-3/4 in (14.61 cm) |
Interchanges & Equivalent parts:
| 14M052AM |
| 14M052M |
| 5016 |
| 84135016 |
| SIG5016 |
| TL5016 |
| TLD5016 |
| TRL5016 |
| 80382R |
| 1671853C91 |
| 5016S1G |
| 8413-5016 |
| LIT5016 |
| TL 5016 |
| 53722GR0 |
| GRT53722 |
| 53722 |
