Treadle Pump - Air Actuated Hydraulic 10
#OTC4064
Product Overview
Thousands of users have put Vanguard to work in a variety of hydraulic power applications. And the reputation for trouble-free performance this pumping unit has earned is a proven, documented fact, not just a sales claim.
Features & Benefits
- Vanguard is a fast-acting, precision-built, two-stage pumping unit consisting of a gear pump for the low-pressure stage and an axial-piston pump for the high-pressure stage, the latter being ?supercharged? by the gear pump.
- Vanguard delivers low volume at high pressure, yet provides high volume at low pressure for fast cylinder piston approach and return.
- The unit features a 10,000 PSI universal motor, which starts under full load. It is suitable for operation up to 10,000 PSI. Motor is 1-1/8 h.p., 12,000 RPM, (27 amp draw). Rated for intermittent duty.
Specifications
| Contents | (1) Pump |
| Treadle Pump Foot Operated | No |
| Treadle Pump Maximum PSI Output | 10,000 PSI |
