1550 B/S COUPLING END YOKE
#SPI4-4-2051-1
Specifications
| Bearing Cap Diameter | 1-3/8 po |
| Center Line to End of Hub | 3-25/32 po |
| C/L To C/L | 1.914 |
| Hub Diameter | 2-5/16 po |
| Involute Spline | No |
| Joint Angle | 22 deg |
| Length Thru Hole (Q) | 2 |
| Material | Acier |
| Outside Yoke Dimension (in.) (E) | 4.964 |
| Package Type | Individuel |
| Series | 1550 |
| Spline Diameter | 1-1/2 po |
| Type | Joug à trou cannelé |
| Weight (lbs) | 0.32 |
| Yoke Style | BS |
| Yoke Type | Winged |
Interchanges & Equivalent parts:
| 4-4-2051 |
| 155TYS24 1 |
| 4420511 |
| 4420511S |
| D4420511 |
| E4420511 |
| SP 4 4 2051 1 |
| SP 4420511 |
| TWD4420511 |
| 442051 |
| 4-4-2051-1 |
