Stop/Tail/Turn Light, Red, Round
#TRL40302R
Product Overview
40 Series, Incandescent, Red, Round, 1 Bulb, Stop/Turn/Tail, Black Grommet Mount, Hardwired, Stripped End/Ring Terminal, 12V, Kit
Features & Benefits
- Grommet features flush mounting in a 4-1/2"
- hole
- Grommet kit includes lens, housing, socket assembly with bulb, grommet and ground screws
Specifications
| Couleur | Rouge |
| Taille commune | 4 po (10,16 cm) |
| Major actuel | 2,1 amp |
| Mineure actuelle | 0,48 amp |
| Profondeur | 2-19/32 po (6,58 cm) |
| Coquille de diamant (O/N) | Non |
| Hauteur | 5-1/2 po (13,97 cm) |
| Couleur du boîtier | Noir |
| Trousse (O/N) | Oui |
| Length | 5-1/2 po (13,97 cm) |
| Lens Material | Polycarbonate |
| Material | PVC |
| Mount Type | Montage à oeillet |
| Number Of Wires | 3 |
| Plug Side One | Câblé |
| Plug Side Two | Extrémité dénudée |
| Reflectorized (Y/N) | Non |
| Series | Série 40 |
| Shape | Rond |
| Standard | FMVSS 108, NSVAC 108, DOT, SAE |
| Technology | Incandescent |
| Type | Stop/Tail/Turn Light |
| VMRS Code | 034-002-013 |
| Volt | 12V |
| Width | 5-1/2 po (13,97 cm) |
| Wire Gauge | 16 ga |
Interchanges & Equivalent parts:
| 5119251001 |
| 110525154 |
| 115872 |
| 1223864 |
| 5004160 |
| 841340302R |
| 70509899 |
| 75089397 |
| 40302R |
| 70999900731 |
| 7583 |
| N14662 |
| HT50602484 |
| TL40302R |
| TLD40302R |
| MTL070445 |
| JE1503054 |
| 2843 |
| TRU40302R |
| LIT40302R |
| TL 40302R |
| TL 40302R |
| 4042 |
| 104149 |
| 83159 |
