High Mounted Stop Light, Red, Rectangular
#TRL45007R
Product Overview
45 Series, CHMSL Products, Incandescent, High Mounted Stop Light, 1 Bulb, Rectangular Red Polycarbonate, Black Grommet Mount, PL-2, Stripped End/Ring Terminal, 12V, Kit
Features & Benefits
- Features high mount stop function when center mounted on the top rear of the vehicle
- Heavy duty shock-mounted bulb
- Recommended for use in center high mounted stop lamp applications
Specifications
| Color | Red |
| Common Size | 3 in (7.62 cm) |
| Current Major | 1.44 amp |
| Depth | 1-15/16 in (4.93 cm) |
| Height | 4-27/64 in (11.23 cm) |
| Housing Color | Black |
| Kit (Y/N) | Yes |
| Length | 6-19/64 in (16 cm) |
| Lens Material | Polycarbonate |
| Material | PVC |
| Mount Type | Grommet Mount |
| Number Of Wires | 3 |
| Plug Side One | PL-3, Female |
| Plug Side Two | PL-2 (Stripped End) |
| Series | 45 Series |
| Shape | Rectangular |
| Standard | FMVSS 108, CMVSS 108, DOT, SAE |
| Technology | Incandescent |
| Type | High Mounted Stop Light |
| VMRS Code | 034-002-040 |
| Volt | 12V |
| Width | 6-19/64 in (16 cm) |
| Wire Gauge | 16 ga |
Interchanges & Equivalent parts:
| HT50602663 |
| TL45007R |
| TLD45007R |
| 195-00-122 |
| 8413-45007R |
| LIT45007R |
| TL 45007R |
| TL 45007R |
| 450KR |
| 45007R |
