Marker Clearance Light, Amber & Yellow, Round
#TRL19002Y
Product Overview
19 Series, Base Mount, Incandescent, Yellow Rectangular, 2 Bulb, Marker Clearance Light, PC, Gray Polycarbonate 2 Screw, Hardwired, Stripped End, 12V, Kit
Features & Benefits
- Features unique plug-in design for ease of installation
- Low-profile, extra-strength base
Specifications
| Amps | 0.66 amp |
| Color | Amber |
| Common Size | 1 in (2.54 cm) |
| Contents | Gray Mount, Lamp, Plug |
| Current Major | 0.33 amp |
| Depth | 51/64 in (2.03 cm) |
| Diamond Shell (Y/N) | No |
| Function | P2, P3, PC, PC2 |
| Height | 1-3/32 in (2.77 cm) |
| Housing Color | Gray |
| Kit (Y/N) | Yes |
| Length | 3-25/32 in (9.6 cm) |
| Lens Material | Polycarbonate |
| Material | Polycarbonate |
| Mount Type | Bracket Mount |
| Number Of Wires | 2 |
| Plug Side One | PL-2 (Stripped End) |
| Plug Side Two | PL-2 (Stripped End) |
| Reflectorized (Y/N) | No |
| Series | 19 Series |
| Shape | Round |
| Standard | FMVSS 108, CMVSS 108, DOT, SAE |
| Technology | Incandescent |
| Type | Marker Clearance Light |
| VMRS Code | 034-004-024 |
| Volt | 12V |
| Width | 4-3/32 in (10.39 cm) |
| Wire Gauge | 16 ga |
Interchanges & Equivalent parts:
| 19002Y |
| 19002Y3 |
| TL19002Y |
| TL19002Y3 |
| TLD19002Y3 |
| TRL19200Y3 |
| TRU19002Y |
| 19001Y |
| 19002Y1 |
| 253-454 |
| 253454 |
| MNC253-454 |
| TRL19001Y |
| 19002Y-TL |
| 3946821 |
| 55620106 |
| 576-0175 |
| 800-250352A |
| 8413-19002Y |
| LIT19002Y |
| MC-67AB |
| TL 19002Y |
| TL 19002Y |
| TLD19002Y |
| 150KA |
| 154KA |
| 1812420864 |
| 1900A |
| 45093GR0 |
| 9560-3 |
| GRT46743 |
| KT2140A |
| LT19KY |
| TKL19002Y |
| 45093 |
| PA10022 |
| 450933 |
| 5760175 |
| 45093-3 |
