Feu de gabarit, ambre et jaune, rond
#TRL30055Y
Sommaire du produit
Série 30, LED, rond jaune, 3 diodes, feu de gabarit, P3, montage sur œillet en PVC noir, Fit 'N Forget M/C, femelle PL-10, 12-24 V, kit
Caractéristiques et avantages
- P2/P3 Rated marker & clearance lamps are compliant for 90 degree
- Low-profile design to reduce damage from being hit or knocked off.
- Designed with LED lighting technology providing optimal light output and sealed design further protecting against damage from shock and vibration.
Spécifications
| Color | Amber |
| Common Size | 2 in (5.08 cm) |
| Current Major | 0.05 amp |
| Depth | 1-3/8 in (3.51 cm) |
| Diamond Shell (Y/N) | No |
| Height | 2 in (5.08 cm) |
| Housing Color | Black |
| Kit (Y/N) | Yes |
| Lens Material | Polycarbonate |
| Material | Polycarbonate |
| Mount/Trim Material | PVC |
| Mount Type | Grommet Mount |
| Number Of Wires | 2 |
| Plug Side One | Fit 'N Forget M/C |
| Plug Side Two | PL-10, Female |
| Reflectorized (Y/N) | No |
| Series | 30 Series |
| Shape | Round |
| Standard | FMVSS 108, CMVSS 108, DOT, SAE |
| Technology | LED |
| Type | Marker Clearance Light |
| VMRS Code | 034-004-253 |
| Volt | 12V & 24V |
| Width | 2 in (5.08 cm) |
| Wire Gauge | 16 ga |
Interchanges et pièces équivalentes:
| 30055Y |
| 1150150002T |
| TLD30055Y |
| 8413-30055Y |
| LIT30055Y |
| TL 30055Y |
| TL30055Y |
