Truck-Lite 36 Series Red Rectangular 3-Diode LED Marker Clearance Light, Hardwired, Adhesive Mount
#TRL36115R
Product Overview
36 Series Truck-Lite marker clearance light featuring a red rectangular polycarbonate lens with 3 LED diodes. Hardwired design with rear exit wire and .180 bullet terminal, operating at 12V. Adhesive mount allows installation without brackets or screws. Durable, epoxy-sealed electronics resist moisture and corrosion, reducing damage and heat entrapment. Complies with FMVSS 108, CMVSS 108, DOT, and SAE standards.Marker Clearance Light, 3 Diode, LED Bulb, Hardwired, Adhesive, Polycarbonate, Red, 9.12 in H, 0.03 in L, Light Function: P2, PC, 36 Series, Rectangular, 12 V, Warranty: Limited Lifetime, 1.53 in W
Features & Benefits
- Provides a clearance/marker solution that requires no mounting brackets or installation screws
- Lamps adhere directly to application surface through the use of heavy-duty adhesive backing
- Easy-to-install peel-off liner
- Hardwired lamp design is easily retrofit able
- Rear exit wire version requires a 3/8 mounting hole, and self-seals hole upon installation
- Side mount options can be mounted without any mounting holes
- LEDs draw much less current, allowing more power for other vehicle requirements
- A PC rated legal lamp allows for one lamp instead of two to meet the 180 degrees
- Hard-Wired Lamp Design Is Easily Retrofitable. Requires No Mounting Brackets Or Installation Screws.
- Electronics are completely sealed in epoxy to resist damage caused by moisture and corrosion
- Reduces lighting costs caused by physical damage and heat entrapment
Specifications
| Bulb Type | LED |
| Connection Type | Hardwired |
| Contents | Lamp, Non-Winged, Rear Exit Wires |
| Diamond Shell (Y/N) | No |
| Height | 9-1/8 in |
| Housing Color | Black |
| Kit (Y/N) | No |
| Length | 3/4 in |
| Lens Color | Red |
| Lens Material | Polycarbonate |
| Material | Polycarbonate |
| Mounting Type | Adhesive |
| Mount Type | Adhesive Mount |
| Number Of Wires | 2 |
| Plug Side One | PL-2 (Stripped End) |
| Plug Side Two | .180 Bullet, Standard |
| Quantity | 5 |
| Reflectorized (Y/N) | No |
| Shape | Rectangular |
| Standards | FMVSS 108, CMVSS 108, DOT, SAE |
| Technology | LED |
| Type | Marker Clearance Light |
| UPC | 735111177913 |
| VMRS Code | 034-004-253 |
| Volt | 12V |
| Voltage Rating | 12 V |
| Warranty | Limited Lifetime |
| Weight | 0.03 lb |
| Width | 1-17/32 in |
| Wire Gauge | 20 ga |
| Wire Length | 6 in |
| Current Rating | 0.03 amp |
| Light Function | P2, PC |
| Product Line | 36 Series |
| Product Category | Marker Clearance Light |
Interchanges & Equivalent parts:
| 36115R |
| TL36115R |
| 36115RTLT |
| TKL36115R |
| TLD36115R |
