MegaCrimp Male Flat-Face O-Ring, 8G-8MFFOR
#GATG25225-0808
Product Overview
Gates MegaCrimp Couplings are Designed for use w/ Gates Wire Braid Hydraulic Hose to Create a Robust, Leak-Free Assembly. The Pre-Assembled Coupling is Designed w/ a Patented C Insert Attached to the Ferrule.
Features & Benefits
- Surpassed one million impulse cycles during design testing.
- MegaCrimp couplings set a new standard for hydraulic couplings. The unique "C" insert ensures "weep-free" concentric crimping to keep equipment and the environment clean.
- One of the most common causes of hydraulic leaks is a cracked coupling nut or seat due to over-torquing by a strong-armed worker. Gates has engineered a solution – Full-Torque Nut technology now available on Gates MegaCrimp and GlobalSpiral couplings.
- SAE J1453 Captive O-Ring Groove for Improved O-Ring Retention.
- Robust Bite-the-Wire Crimp. Low Profile. Full-Stem Insertion. Full-Length Crimp. Tested to Industry-Leading 600,000 Impulse Cycles.
- Simplifies Inventory Management. Environmentally-Friendly TuffCoat Plating for 345 Percent Better Corrosion Resistance than SAE Standard.
- One MegaCrimp Coupling Size can Accommodate Various 1 and 2 Wire Braid Hydraulic Hoses of Different Constructions & Wall Thicknesses, Simplifying Inventory Requirements, Helping to Reduce Costs & Simplifying Coupling Selection.
Specifications
| Angle | 0 deg |
| Description d'accouplement | MegaCrimp Male Flat-Face O-Ring |
| Coupure (po) – C | 1-13/64 po (3,05 cm) |
| Type de raccords | Mâle |
| Recommandations pour le tuyau | Peut s'adapter à différents diamètres extérieurs de tuyaux sur des tuyaux hydrauliques tressés à un ou deux fils. |
| Description industrielle | 8G-8MFFOR |
| Diamètre intérieur | 1/2 po (1,27 cm) |
| Longueur | 2-11/16 po (6,83 cm) |
| Note | Rainure de Joint Torique captive SAE J1453 pour une meilleure rétention du Joint Torique. |
| N° de pièce d'origine | G25225-0808 |
| Joint torique | Joint Torique à face plate |
| Numéro de produit | 710416115 |
| Type de joint d'étanchéité | Joint Torique |
| Diamètre intérieur du manchon | 55/64 po (2,18 cm) |
| Tige hexagonale (po) | 55/64 po (2,18 cm) |
| Pivot | Non |
| Filetage | 13/16 po-16 |
| Type | Joint torique à face plate mâle MegaCrimp |
Interchanges & Equivalent parts:
| 147300808 |
| GYH14730-0808 |
| 1AA8MR8 |
| G25225-0808 |
| 710416115 |
