Pedestal Light, Red, Round
#TRL70330Y
Product Overview
Incandescent, Yellow Round, 1 Bulb, Single Face, 1 Wire, Pedestal Light, 1 Stud, Gray, Blunt Cut
Features & Benefits
- Available as single or dual face lamps
- Dual face lamp mounts on a 3/8"-24 stud
- Single face lamp mounts on a 7/16" -14 stud
- Features snap-in lens
- LED Upgrade options available #2751, 2751A and 2750
Specifications
| Couleur | Ambre |
| Taille commune | 4 in (10.16 cm) |
| Contient | Lampe |
| Major actuel | 2,1 amp |
| Profondeur | 1-15/16 in (4.93 cm) |
| Finition | Gray |
| Fonction | I, S |
| Hauteur | 4-7/32 in (10.72 cm) |
| Trousse (O/N) | No |
| Longueur | 4-47/64 in (12.01 cm) |
| Matériau de la lentille | Polycarbonate |
| Type de support | Montage par goujon |
| Nombre de câbles | 1 |
| Fiche #1 | PL-2 (Stripped End) |
| Fiche #2 | PL-2 (Stripped End) |
| Position | Left or Right Sides |
| Forme | Rond |
| Simple ou double | Seul |
| Standard | FMVSS 108, DOT, SAE |
| Technologie | Incandescent |
| Type | Pedestal Light |
| Code VMRS | 034-003-071 |
| Volt | 12V |
| Largeur | 4-1/4 in (10.8 cm) |
| Calibre de(s) fil(s) | 16 ga |
Interchanges & Equivalent parts:
| 4204968 |
| 24530 |
| 7622101 |
| 3946866 |
| 841370330Y |
| 70330Y |
| 71021 |
| 7590000117 |
| HT50602741 |
| TL70330Y |
| TLD70330Y |
| 129893 |
| 2701A |
| 3753AD |
| 3761A |
| 70330Y1 |
| 70330Y3 |
| TRU70330Y |
| 3751A |
| 762-2101 |
| 8413-70330Y |
| LIT70330Y |
| TL 70330Y |
| TL 70330Y |
| 157-00-512 |
| 313AA |
| 706063 |
| 55243 |
