MegaCrimp Female JIC 37 Flare Swivel x 90° Bent Tube Coupling, Steel, 3/4-16 x 1/2 in, 8G-8FJX90M
Product Overview
Gates MegaCrimp Couplings are designed for use with Gates wire braid hydraulic hose to create a robust, leak-free assembly. The pre-assembled coupling features a patented "C" insert that allows usage with different hose constructions and wall thicknesses, ensuring an even distribution of crimping forces for a concentric, weep-free seal. This innovation simplifies inventory management by accommodating various hose outside diameters on both one-wire and two-wire braid hydraulic hoses. MegaCrimp couplings are fully qualified to EN performance standards and provide superior reliability and environmental protection.MegaCrimp Coupling, Steel, 3/4-16 Connection Size 1, 1/2 in Connection Size 2, Female JIC 37 deg Flare Swivel Connection Type 1, 90 deg Bent Tube Connection Type 2, 3.04 in Length
Features & Benefits
- Surpassed one million impulse cycles during design testing.
- MegaCrimp couplings set a new standard for hydraulic couplings. The unique "C" insert ensures "weep-free" concentric crimping to keep equipment and the environment clean.
- One of the most common causes of hydraulic leaks is a cracked coupling nut or seat due to over-torquing by a strong-armed worker. Gates has engineered a solution – Full-Torque Nut technology now available on Gates MegaCrimp and GlobalSpiral couplings.
- Robust Bite-the-Wire Crimp. Low Profile. Full-Stem Insertion. Full-Length Crimp. Tested to Industry-Leading 600,000 Impulse Cycles.
- Simplifies Inventory Management. Environmentally-Friendly TuffCoat Plating for 345 Percent Better Corrosion Resistance than SAE Standard.
- One MegaCrimp Coupling Size can Accommodate Various 1 and 2 Wire Braid Hydraulic Hoses of Different Constructions & Wall Thicknesses, Simplifying Inventory Requirements, Helping to Reduce Costs & Simplifying Coupling Selection.
Specifications
| Length | 3-3/64 in |
| Material | Steel |
| Type | MegaCrimp Female JIC 37 Flare Swivel - 90 deg Bent Tube |
| Connection Size 1 | 3/4-16 |
| Connection Size 2 | 1/2 in |
| Connection Type 1 | Female JIC 37 deg Flare Swivel |
| Connection Type 2 | 90 deg Bent Tube |
| Standards | EN performance standards |
| Product Category | MegaCrimp Coupling |
| Weight | 0.4 lb (0.18 kg) |
Interchanges & Equivalent parts:
| 144250808 |
| GYHB2-JCFX90-0808 |
| GYH14425-0808 |
| B2JCFX900808 |
| B2-JCFX90-0808 |
| 08U668 |
| G251800808 |
| SC63988 |
| 1AA8FJB8 |
| FJ9132-0808S |
| G25180-0808 |
| 710347295 |
