ASA, Spline: 1-1/2 in - 10, L: 5 in
#ROCR802261
Specifications
| Arm Length # 1 | 5 in |
| Automatic or Manual | Automatic |
| Chamber Sizes | 9 in (22.86 cm) |
| Clevis Thread Diameter (in.) | 1/2 in (1.27 cm) |
| Clevis Threads per inch | 20 in (50.8 cm) |
| Clevis Type | Straight |
| Maximum Torque | More than 45 inch pounds |
| Model | Meritor |
| Notes | Black piston. Drum brake. |
| Number of Splines | 10 |
| Production Part Number | A26-3275-Y-1143 |
| Spline Diameter | 1-1/2 in (3.81 cm) |
| Spline Diameter-Spline Count | 1-1/2 in - 10 |
| Type | Stroke-Sensing |
Interchanges & Equivalent parts:
| A5-3275-Y-1143S |
| TDA R802261 |
| TDAR802261 |
| 05-560 |
| A8-3275-Z-598S |
| AS1031 |
| E6991A |
