ASA, Spline: 1-1/2 in - 28, L: 5 in
#EUCE6993B
Features & Benefits
- Enhances vehicle safety by promoting proper brake function
- Extends service life of brake linings by ensuring even wear
- Maintains optimal brake shOE-to-drum clearance for safe braking
- Compatible with standard brake systems for versatile application
- Minimizes the need for manual adjustments, saving time and effort
- Improves overall brake system efficiency for reliable stopping power
- Ensures consistent braking performance under various load conditions
- Facilitates automatic adjustment to compensate for brake lining friction
Specifications
| Application | Tracteur & Remorque |
| Arm Length # 1 | 5 po |
| Automatic or Manual | Automatique |
| Brake Size | 16-1/2 po (41,91 cm) |
| Clevis Thread Diameter (in.) | 5/8 po (1,59 cm) |
| Clevis Threads per inch | 18 po (45,72 cm) |
| Clevis Type | Droit |
| Maximum Torque | Moins de 10 pieds de livres ou plus de 33 pieds de livres |
| Model | Sans Contrôle automatique |
| Notes | Jeu de valeur |
| Number of Splines | 28 |
| Spline Diameter | 1-1/2 po (3,81 cm) |
| Spline Diameter-Spline Count | 1-1/2 po - 28 |
| Type | Détection de jeu |
Interchanges & Equivalent parts:
| 05-562 |
| 11-355 |
| 41421109 |
| CB22103 |
| CI22103 |
| CS52321 |
| H-2003 |
| L-3005 |
| M-3368 |
| SA22103 |
| L3161 |
| M3368 |
| H2003 |
| WA22103 |
