ASA, Spline: 1-1/2 in - 28, L: 5 in
#ROCR802403
Specifications
| Arm Length # 1 | 5 in |
| Automatic or Manual | Automatic |
| Chamber Sizes | 9 in (22.86 cm) |
| Clevis Thread Diameter (in.) | 1/2 in (1.27 cm) |
| Clevis Threads per inch | 20 in (50.8 cm) |
| Clevis Type | Offset 0.625 in. |
| Maximum Torque | More than 45 inch pounds |
| Model | Meritor |
| Notes | Black piston. Drum brake. |
| Number of Splines | 28 |
| Production Part Number | A22-3275-Y-1143 |
| Spline Diameter | 1-1/2 in (3.81 cm) |
| Spline Diameter-Spline Count | 1-1/2 in - 28 |
| Type | Stroke-Sensing |
Interchanges & Equivalent parts:
| 8235-R802403 |
| A113275Y1143S |
| ATIR802403 |
| TDAR802403 |
| E-6993A |
| 05-562 |
| AS1039 |
