MSA, Spline: 1-1/2 in - 10, L: 5 in, 6 in, 7 in
#ROCR824000B10
Features & Benefits
- Meets FMVSS-121 standards
- Allows for easy manual operation
- Extends brake component lifespan
- Increases brake system efficiency
- Provides precise brake adjustment
- Ensures proper brake shoe clearance
- Reduces brake maintenance frequency
- Enhances vehicle safety on the road
Specifications
| Longueur de bras #1 | 5 po, 6 po et 7 po |
| Automatique ou manuel | Manuel |
| Type de chape | Droit |
| Diamètre du filetage de la chape (po) | 1/2 po (1,27 cm) |
| Couple maximal | 22000 |
| Notes | 22,000 lbs maximum, Economy slack |
| Number of Splines | 10 |
| Spline Diameter | 1-1/2 po (3,81 cm) |
| Spline Diameter-Spline Count | 1-1/2 po - 10 |
Interchanges & Equivalent parts:
| R822000B10 |
| 8235-R824000B10 |
| ATIR824000B10 |
| MERR824000B10 |
| TDA R824000B10 |
| TDAR824000B10 |
