Littelfuse 12V 17.5 Ohm Insulated Solenoid Relay, 200A Continuous, SPST, Plated Steel Housing
Product Overview
The Littelfuse 24213 is a 12 V, 200 A continuous-duty insulated solenoid relay designed for heavy-duty applications. Featuring a plated steel housing and single-pole, single-throw (SPST) normally open contacts, this relay includes a coil impedance of 17.5 ohms. The insulated coil design electrically isolates the studs from the housing, ensuring reliable operation. Equipped with two large 5/16-24 in copper power studs and two small #10-32 steel coil studs, it is built to handle motor and inductive loads in construction vehicles, material handling, and agricultural equipment.Solenoid Relay, Insulated, SPST Contact, Silver Contact, Plated Steel, 200 A, 12 V, For Construction Vehicles, Material Handling, Agricultural Equipment, Motor and Inductive Loads
Features & Benefits
- 200 A continuous current rating
- 12 V coil with 17.5 ohm coil impedance
- Insulated coil design electrically isolates studs from housing
- SPST circuitry with normally open contacts
- Two large 5/16-24 in copper power studs and two small #10-32 steel coil studs (control circuit) are heavy and durable
- Flat bracket included
- Hex nuts and lock washers included in bag
Specifications
| Application | Véhicules de construction, Manutention, Équipements agricoles, Charges motrices et inductives |
| Matériau de contact | Argent |
| Matériau du boîtier | Acier plaqué |
| Number Of Contacts | 1 |
| Type | Isolé |
| Contact Type | SPST |
| Current Rating | 200 A |
| Flash Rate | 17,5 Ohm |
| Voltage Rating | 12 V |
| Product Category | Relais solénoïde |
Interchanges & Equivalent parts:
| 24143 |
| COH24143 |
| COL24143 |
| COH24143-BX |
