Air Spring, Rolling Lobe Air Spring, 5100 lb at 80 psi, 6400 lb at 100 psi, 3.9 in Compressed Length, 14.4 in Extended Length, 11.4 in, 8 in Height
#MZH566.ER9422
Product Overview
Air Spring, Rolling Lobe Air Spring, 5100 lb at 80 psi, 6400 lb at 100 psi, 3.9 in Compressed Length, 14.4 in Extended Length, 11.4 in, 8 in Height, For Kenworth
Features & Benefits
- Bellows#: Automann 1DK20D, Firestone 1T15L-1.5, 1T15KW-1.5, Goodyear 566-22-3-021, Contitech 9 9-12, Triangle 6368
- 80 cpm natural freq
- Plastic bottom plate type
- Top plate hole/stud qty: 2
- Top plate dia. (A): 9
- Top plate C to C dia. (B): 6.2
- Bottom plate hole/stud qty: 2
- Bottom plate dia. (C): 9.53
- Bottom plate C to C dia. (D): 4.09
- Bottom part#: BS08624
Specifications
| Air Spring Type | Rolling Lobe |
| Application | Kenworth |
| Compressed Length | 3.9 in |
| Extended Length | 14.4 in |
| Height | 8 in |
| Quantity | 1 |
| UPC | 889626398193 |
| Weight | 11.84 lb |
| Capacity | 5100 lb at 80 psi, 6400 lb at 100 psi |
| Fitting Size | 11.4 in |
| Manufacturer Part Number | 566.ER9422 |
| Product Category | Air Spring |
