Signal-Stat, The Guardian, Incandescent, Red Rectangular, 1 Bulb, Marker Clearance Light, PC, Silver Steel 4 Screw Mount, Hardwired, Stripped End, 12V
#TRL1105
Product Overview
Signal-Stat, The Guardian, Incandescent, Red Rectangular, 1 Bulb, Marker Clearance Light, PC, Silver Steel 4 Screw Mount, Hardwired, Stripped End, 12V
Features & Benefits
- Fully protected lens ensures durability and longevity
- Pressure pad tightly seals lens to prevent moisture ingress
- High guard design offers enhanced protection against impacts
- Designed for marker and clearance applications for versatility
- Quick-click lamp removal simplifies maintenance and replacement
- Ideal for various vehicle lighting needs with reliable performance
Specifications
| Compliance Family | FMVSS 108 |
| Contents | Lamp |
| Current Major | 0.35 amp |
| Depth | 1-3/4 in (4.45 cm) |
| Diamond Shell (Y/N) | No |
| Fits Pigtail Part #(s) | Hard Wired |
| Height | 1-7/8 in (4.78 cm) |
| Housing Material | Polycarbonate |
| Kit (Y/N) | No |
| Lamp Color | Red |
| Lamp Length | 4.87 in. |
| Lamp Material | Polycarbonate Lens, Housing, Gasket, Steel Mount |
| Lamp SAE Rating | P2 |
| Lamp Shape | Rectangular |
| Lamp Style | The Guardian Deflector Mount |
| Lamp Type | Sealed Incandescent |
| Lamp Volt Rating | 12 Volts |
| Lamp Width | 1.87 in. |
| Lamp Wire Length | 3 in. |
| # Lamp Wires | 1 |
| Lens Color | Red |
| Lens Height | 1-19/64 in (3.3 cm) |
| Lens Material | Polycarbonate |
| Lens Shape | Rectangular |
| Lens Width | 2-1/16 in (5.23 cm) |
| Lighting Technology | Incandescent |
| Mounting Connector Diameter (in.) | 3/8 in (0.97 cm) |
| Mounting Method | Mount Through Id Bar |
| Mount/Trim Color | Silver |
| Mount/Trim Material | Steel |
| Mount Type | Screw Mount |
| Number of Diodes/Bulbs | 1 |
| Number Of Wires | 1 |
| Packaging | Polybag |
| Plug Side One | Hardwired |
| Plug Side Two | Stripped End |
| Product Type | Marker Clearance Light |
| Reflectorized (Y/N) | No |
| Series | Signal-Stat |
| VMRS Code | 034-004-021 |
| Volt | 12V |
| Weight | 0.5 lbs (0.23 kg) |
| Width | 4-7/8 in (12.4 cm) |
| Wire Gauge | 18 |
Interchanges & Equivalent parts:
| 1105 |
| 45172 |
| SIG1105 |
| TL1105 |
| TLD1105 |
| 1105-3 |
| 468925 |
| 8413-1105 |
| LIT1105 |
| TL 1105 |
| 1105S1G |
| 45172GR0 |
| V122XR |
