Muffler, Le: 21 in
#DONM120566
Product Overview
Why Choose Donaldson?
Features & Benefits
- Donaldson delivers a full line of aftermarket liquid, lube, air, hydraulic, and exhaust system components.
- Products and technology designed to consistently meet required specifications – and your expectations.
- Superior performance in thousands of on- and off-road applications.
Specifications
| Plage basse d'atténuation | 12 dBA |
| Gamme haute d'atténuation | 17 dBA |
| Gamme haute de contre-pression (métrique) | 76 mm HG |
| Gamme haute de contre-pression | 2,99 po HG |
| Plage basse de contre-pression | 0,98 po HG |
| Contre-pression milieu de gamme | 2,01 po HG |
| Back Pressure Low-Range (Metric) | 25 mm HG |
| Back Pressure Mid-Range (Metric) | 51 mm HG |
| Body Diameter | 10 po (25,4 cm) |
| Body Diameter Max | 15 po (38,1 cm) |
| Body Length | 20-63/64 po (53,3 cm) |
| Inlet Clock Position | 3:00 |
| Inlet Diameter | 4 in (10.16 cm) |
| Length | 21 po (53,34 cm) |
| Outlet Clock Position | 3:00 |
| Outlet Diameter | 5 po (12,7 cm) |
| Overall Length | 25-5/8 po (65,09 cm) |
| Rated Flow High Range | 2203,63 pi³/min (62,4 m³/min) |
| Rated Flow Low Range | 1271,33 pi³/min (36 m³/min) |
| Rated Flow Mid Range | 2203.63 cfm (62.4 m³/min)[delete] |
| Length Range | 20 à 21 po |
| Style | Style 2 |
Interchanges & Equivalent parts:
| 3931 |
| M542 |
| 86542M |
| M34510X15 |
| 1901220 |
| 3718 |
| E705 |
| 7642100009 |
| 31566 |
| DCM120566 |
| J7H0053 |
| 2ME3106A |
| EEM1899 |
| 13000544 |
| D132070 |
| 31566HDM |
| 2191-M120566 |
| 30566 |
| DN M120566 |
| DN M120566 |
| FG 86542M |
| DONM120566 |
| EEM-1899 |
| M-542 |
| M3-4510X15 |
| NFM86542M |
| 21161 |
