| Attenuation Low Range |
15 dBA |
| Attenuation High Range |
20 dBA |
| Back Pressure High-Range (Metric) |
76 mm HG |
| Back Pressure High Range |
2.99 in HG |
| Back Pressure Low Range |
0.98 in HG |
| Back Pressure Mid Range |
2.01 in HG |
| Back Pressure Low-Range (Metric) |
25 mm HG |
| Back Pressure Mid-Range (Metric) |
51 mm HG |
| Body Diameter |
8-1/2 in (21.59 cm) |
| Body Length |
27 in (68.58 cm) |
| Inlet Clock Position |
3:00 |
| Inlet Diameter |
3-1/2 in (8.89 cm) |
| Length |
27 in (68.58 cm) |
| Outlet Clock Position |
6:00 |
| Outlet Diameter |
3 in (7.62 cm) |
| Overall Length |
29-1/2 in (74.93 cm) |
| Rated Flow High Range |
801.64 cfm (22.7 m³/min) |
| Rated Flow Low Range |
462.62 cfm (13.1 m³/min) |
| Rated Flow Mid Range |
801.64 cfm (22.7 m³/min)[delete] |
| Length Range |
27 to 28 in |
| Style |
Style 3 |
