| Attenuation Low Range |
19 dBA |
| Attenuation High Range |
25 dBA |
| Back Pressure High-Range (Metric) |
76 mm HG |
| Back Pressure High Range |
2.99 in HG |
| Back Pressure Low Range |
0.98 in HG |
| Back Pressure Mid Range |
2.01 in HG |
| Back Pressure Low-Range (Metric) |
25 mm HG |
| Back Pressure Mid-Range (Metric) |
51 mm HG |
| Body Diameter |
10 in (25.4 cm) |
| Body Length |
59-59/64 in (152.21 cm) |
| Diameter |
10-5/64 in (25.6 cm) |
| Diameter Range |
5 to 6 in |
| Inlet Diameter |
5 in (12.7 cm) |
| Length |
59-1/4 in (150.5 cm) |
| Outlet Diameter |
5 in (12.7 cm) |
| Overall Length |
66-1/2 in (168.91 cm) |
| Rated Flow High Range |
2610 cfm (73,91 m³/min) |
| Rated Flow Low Range |
1505 cfm (43 m³/min) |
| Rated Flow Mid Range |
2610 cfm (73,91 m³/min)[delete] |
| Length Range |
More than 50 in |
| Style |
Style 1 |
